Overview
| Place of Origin: | ZheJiang, China |
| Brand Name: | UNIV |
| Model Number: | UN3000E-A |
| Certification: | CE/ISO9001 |
| Engine Brand: | YUNNEI |
| Minimum Order Quantity: | 1 unit |
| Delivery Time: | 30-40day |
| Warranty | 1 year |
Quick Detail
PRIME POWER: 23.5KW
ENGINE: E2H999E-B
Engine/Alternator RPM(rpm): 3600
DIMENSION(mm):1390*800*850
Specifications
| MODEL | UN12400E-A | UN26000E-A | UN26000E-A | UN3000E-A |
| FUEL TYPE | NG.LPG | NG.LPG | NG.LPG | NG.LPG |
| GEN-SET OUTPUT POWER | ||||
| RATED POWER(GASOLINE) | ― | ― | ― | ― |
| RATED POWER(LPG) | 8.5KW | 13KW | 17KW | 20KW |
| MAX POWER (LPG) | 9.3KW | 14.5KW | 18KW | 22kw |
| RATED POWER(NG) | 7.7KW | 13KW | 16KW | 18kw |
| MAX POWER (NG) | 8.4KW | 14.5KW | 17KW | 20kw |
| RATED VOLT (V) | 230 | 230 | 230 | 230 |
| RATED CURRENT(GASOLINE) | ― | ― | ― | ― |
| RATED CURRENT(LPG) | 37 | 56.5 | 73.9 | 87.0 |
| RATED CURRENT(NG) | 33 | 56.5 | 69.6 | 78.26 |
| PHASE | SINGLE | SINGLE | SINGLE | SINGLE |
| Engine/Alternator RPM(rpm) | 3000 | 3000 | 3000 | 3000 |
| HZ | 50 | 50 | 50 | 50 |
| POWER FACTOR | 1 | 1.0 | 1.0 | 1.0 |
| ENGINE SPECIFICATION | ||||
| ENGINE MODEL | UNIV | UNIV | UNIV | UNIV |
| ENGINE PART # | R500D-V3 | R999D | R999D | E2H999E-B |
| No. of Cylinders and Build | Single | 2 - V type | 2 - V type | 2 - V type |
| DISPLACEMENT(L) | 500CC | 999CC | 999CC | 999CC |
| COMPRESSION RATIO | 8.5:1 | 8.6:1 | 8.6:1 | 8.6:1 |
| IGNITION SYSTEM | Electronic ignition | Electronic ignition | Electronic ignition | Electronic ignition |
| ELECTRIC START | YES | YES | YES | YES |
| STARTING MOTOR | 24V | 24V | 24V | 24V |
| BORE&STROKE(mm×mm) | 94x72 | 99×78.5 | 99×78.5 | 99×78.5 |
| ASPIRATION TYPE | NATURAL ASPIRATION | NATURAL ASPIRATION | NATURAL ASPIRATION | NATURAL ASPIRATION |
| OIL CAPACITY(L) | 1.3L | 2.3L | 2.3L | 2.3L |
| ROTARY OIL FILTER | YES | YES | YES | YES |
| CHARGING METHOD | 12V/7A charhing coil | 12V/7A charhing coil | 12V/7A charhing coil | 12V/7A charhing coil |
| RECOMMEND BATTERY START CURRENT(CCA) | ? | 500CCA | 500CCA | ? |
| COOLING SYSTEM | AIR COOLED | AIR COOLED | AIR COOLED | AIR COOLED |
| LOW OIL PRESSURE SHUTDOWN | YES | YES | YES | YES |
| ECU | YES | YES | YES | YES |
| Gas Valve | YES | YES | YES | YES |
| ALTERNATOR SPECIFICATION | ||||
| TYPE | Synchronous generator, a rotating magnetic field | Synchronous generator, a rotating magnetic field | Synchronous generator, a rotating magnetic field | Synchronous generator, a rotating magnetic field |
| VOLT.REG.SYSTEM | AVR | AVR | AVR | AVR |
| BRUSH | BRUSH | BRUSH | BRUSH | BRUSH |
| POLE | 2 | 2 | 2 | 2 |
| THD @FULL LOAD | ≤ 5% | ≤ 5% | ≤ 5% | ≤ 5% |
| INSULATION | H | H | H | H |
| STATOR WINDING MATERIAL | COPPER | COPPER | COPPER | COPPER |
| ROTOR WINDING MATERIAL | COPPER | COPPER | COPPER | COPPER |
| CONNECTION METHOD | DIRECT COUPLING | DIRECT COUPLING | DIRECT COUPLING | DIRECT COUPLING |
| VOLTAGE STEADY | ||||
| TYPE | ELECTRON | ELECTRON | ELECTRON | ELECTRON |
| Sensing | SINGLE | SINGLE | SINGLE | SINGLE |
| VOLTAGE ADJUSTING | ± 5% | ± 5% | ± 5% | ± 5% |
| GOVERNOR | ||||
| TYPE | 电子 | 电子 | 电子 | 电子 |
| No load to full load frequency regulation | SYNCHRONISM | SYNCHRONISM | SYNCHRONISM | SYNCHRONISM |
| Steady frequency adjustment | ± 2.5% | ± 2.5% | ± 2.5% | ± 2.5% |
| CONTROLER SPECIFICATION | ||||
| CONTROLER BRAND | SMART GEN | SMART GEN | SMART GEN | SMART GEN |
| CONTROLER LOCATION | INSIDE,UP OF ALTERNATOR | INSIDE,UP OF ALTERNATOR | INSIDE,UP OF ALTERNATOR | INSIDE,UP OF ALTERNATOR |
| MANUFATURER/PART# | MGC310 | MGC310 | MGC310 | MGC310 |
| AUTO/MANUAL/SHUT DOWN | YES | YES | YES | YES |
| ALTERNATOR VOLTAGE DETECTION | YES | YES | YES | YES |
| MAINS VOLTAGE DETECTION | NO | NO | NO | NO |
| LOW OIL PROTECTION | YES | YES | YES | YES |
| OVER FREQUENCY PROTECTION | YES | YES | YES | YES |
| LOW FREQUENCY PROTECTION | YES | YES | YES | YES |
| SOUNDPROOF CANOPY SPECIFICATION | ||||
| CANOPY | ALIMINUM | ALIMINUM | ALIMINUM | ALIMINUM |
| WARRANTY(YEAR) | 1 | 1 | 1 | 1 |
| PROTECTION LEVEL | IP 23 | IP 23 | IP 23 | IP 23 |
| EMERGENCY STOP SWITCH | YES | YES | YES | YES |
| FUEL SOLENOID VALVE | YES | YES | YES | YES |
| ENCLOSED MUFFLER | YES | YES | YES | YES |
| SOUND INSULATION | Soundproof cotton | Soundproof cotton | Soundproof cotton | Soundproof cotton |
| NOISE AT NORMAL SPEED ,23ft(7M) dB(A) | ― | ― | ― | ― |
| PET CONSUMPTION100%LOAD gal/hr(L/hr) | ― | ― | ― | ― |
| NG CONSUMPTION 100%LOAD m3/hr | ― | ― | ― | ― |
| LPGCONSUMPTION 100%LOAD kg/hr | ― | ― | ― | ― |
| NG PRESSURE RANGE kPa | 1.3-2 | 1.3-2 | 1.3-2 | 1.3-2 |
| LPG PRESSURE RANGE kPa | 2.4-3.1 | 2.4-3.1 | 2.4-3.1 | 2.4-3.1 |
| GEN-SET DIMENSION | ||||
| NUIT DIMENSION(L×W×H) mm | 1050x600x650 | 1290×675×735 | 1290×675×735 | 1290×675×735 |
| PACKAGE DIMENSION(L×W×H) mm | / | 1390×800×850 | 1390×800×850 | 1390×800×850 |
| NET WEIGHT( kg) | 140(no battery) | - | 245(no battery) | 260(no battery) |
| GROSS WEIGHT(kg) | - | - | - | - |
| 20/40 GP CONTAINER | - | 75(40HQ) | 75(40HQ) | 75(40HQ) |
| BUSSINESS TERM | ||||
| 1. Warranty: General: Air-Cool Type 500 Operation Hours or 1 years, Liquid-Cool Type 1,000 Operation Hours or 1 years which comes first ;US:Air-Cool Type 500 Operation Hours or 2 years, Liquid-Cool Type 1,000 Operation Hours or 5 years which comes first | ||||
